| Model | |||
| Resolution | 5MP | ||
| General | Pixel | 2592*1944 | |
| Main processor | Ingenic-T40N | ||
| Image sensor | GC4653 | ||
| APP operate system | Android, IOS | ||
| Compressed format | H.265 | ||
| Lens | Focal length | Wide Angle lens 2.8mm ball machine lens 5-50mm | |
| Angle | Wide Angle lens 110° ball machine lens 48° | ||
| Internet connection | 4G | TD-LTE,TD-LTE / LTE FDD TD-LTE / LTE-FDD | |
| 4G mode version | China/US/European/Southeast Asia/Japan/Australia (optional) | ||
| Alarm mode | Detection mode | PIR Human sensing +AI human detection | |
| Detection range | 0-12M | ||
| Detection angle | 110°+ 110° | ||
| Alarm mode | Real time mobile phone calling or push message | ||
| PTZ | PTZ angle | 355 ° Horizontal and 100° vertical | |
| Rotational speed | Horizontal 55°/ s Vertical 40°/ s | ||
| Night vision mode | night vision | Illuminance is 0.00LUX | |
| infrared light | Infrared LED distance 40M | ||
| White light | White LED distance 40M | ||
| Voice | Built-in speaker | 3W | |
| Built-in microphone | Monitor range 20M | ||
| Storage | Video mode | Alarm video/timing video/all-day video | |
| Cloud storage | Cloud storage (alarm event video) | ||
| Local storage | TF card (Max 128G) | ||
| Power | Power supply mode | Solar panel + battery | |
| Solar battery sheet material | Monocrystalline silicon | ||
| Solar battery power | 9W | ||
| Battery | 6pcs 18650 battery | ||
| Max working power | 4.5W | ||
| Standby power | 0.003W | ||
| Other | Working area | Indoor/outdoor | |
| working temperature | -30°~+60° | ||
| Working humidity | 0%~90%RH | ||
| Package | Net weight | 1.98KG | |
| Box size | 282*192*182mm | ||
| Packing quantity | 6PCS | ||
| Gross weight | 12.5KG | ||
| Carton size | 610*300*386mm | ||
